피웹1. 피코 블루투스 제어
# 필요한 모듈 임포트
from machine import Pin
import bluetooth
from ble_simple_peripheral import BLESimplePeripheral
import utime
# BLE 객체 생성
ble = bluetooth.BLE()
# BLE 간단한 주변장치 클래스 인스턴스 생성
sp = BLESimplePeripheral(ble)
# 온보드 LED 설정
led_onboard = Pin("LED", Pin.OUT)
led_onboard.value(1) # 연결 확인을 위해 LED 켜기
# LED 핀 설정 (예: GPIO 14, 15, 16번 핀에 LED 연결)
led_red = Pin(27, Pin.OUT)
led_blue = Pin(18, Pin.OUT)
led_yellow = Pin(22, Pin.OUT)
# LED 상태 변수 초기화
led_states = {
'red': 0,
'blue': 0,
'yellow': 0
}
# 수신한 데이터를 처리하는 콜백 함수 정의
def on_rx(data):
print("Data received:", data)
command = data.decode('utf-8').strip() # 데이터를 문자열로 디코딩하고 공백 제거
if command in led_states:
# 해당 LED의 상태를 토글
led_states[command] = 1 - led_states[command]
# LED 상태 적용
led_red.value(led_states['red'])
led_blue.value(led_states['blue'])
led_yellow.value(led_states['yellow'])
# 문자열 포매팅 수정
led_status = 'ON' if led_states[command] else 'OFF'
print(command.upper() + " LED " + led_status)
elif command == 'off':
# 모든 LED 끄기
for key in led_states:
led_states[key] = 0
led_red.value(0)
led_blue.value(0)
led_yellow.value(0)
print("All LEDs OFF")
else:
print("Unknown command")
# 메인 루프
while True:
if sp.is_connected():
sp.on_write(on_rx)
utime.sleep(0.1) # CPU 사용량을 줄이기 위해 약간의 딜레이 추가
Python
복사
추가 코드 업로드
•
피웹2. 피코 웹 데이터베이스 제어
•
피웹3. 피코 웹 블루투스 제어
# Source: electrocredible.com , Language: MicroPython
# Import necessary modules
import machine
import bluetooth
from ble_simple_peripheral import BLESimplePeripheral
# Create a Bluetooth Low Energy (BLE) object
ble = bluetooth.BLE()
# Create an instance of the BLESimplePeripheral class with the BLE object
sp = BLESimplePeripheral(ble)
# Create a Pin object for the onboard LED, configure it as an output
led = machine.Pin("LED", machine.Pin.OUT)
# Initialize the LED state to 0 (off)
led_state = 0
led.on()
# Define a callback function to handle received data
def on_rx(data):
print("Data received: ", data) # Print the received data
sp.send(data)
if data == b'a': # Check if the received data is "toggle"
led.on() # LED 켜기
print("aa")
if data == b'b': # Check if the received data is "toggle"
led.off() # LED 켜기
print("bb")
# Start an infinite loop
while True:
if sp.is_connected(): # Check if a BLE connection is established
sp.on_write(on_rx) # Set the callback function for data reception
Python
복사
•
제어 사이트 예시
•
제어사이트 코드
<!DOCTYPE html>
<html>
<head>
<title>Raspberry Pico Web Bluetooth Serial Monitor</title>
<style>
body {
font-family: Arial, sans-serif;
}
.container {
max-width: 500px;
margin: 0 auto;
padding: 20px;
}
.button {
display: inline-block;
padding: 10px 20px;
font-size: 16px;
background-color: #4CAF50;
color: #fff;
border: none;
cursor: pointer;
}
.button:hover {
background-color: #45a049;
}
.input-field {
width: 100%;
padding: 10px;
font-size: 16px;
border: 1px solid #ccc;
border-radius: 4px;
box-sizing: border-box;
}
</style>
</head>
<body>
<div class="container">
<h2>Raspberry Pico Web Bluetooth Serial Monitor</h2>
<button id="connectButton" class="button" onclick="connectToDevice()">Connect</button>
<button id="disconnectButton" class="button" onclick="disconnectFromDevice()" disabled>Disconnect</button>
<br><br>
<input type="text" id="messageInput" class="input-field" placeholder="Enter message">
<button class="button" onclick="sendMessage()">Send Message</button>
<br><br>
<pre id="log"></pre>
</div>
<script>
let device;
let logElement;
let writeCharacteristic;
let readCharacteristic;
function log(message) {
logElement.innerHTML += message + '\n';
}
async function connectToDevice() {
try {
logElement = document.getElementById('log');
log('Requesting Bluetooth Device...');
if (device && device.gatt.connected) {
log('Already connected to ' + device.name);
return;
}
device = await navigator.bluetooth.requestDevice({
filters: [{ name: 'mpy-uart' }],
optionalServices: ['6e400001-b5a3-f393-e0a9-e50e24dcca9e']
});
log('Connecting to GATT Server...');
const server = await device.gatt.connect();
log('Getting Serial Service...');
const service = await server.getPrimaryService('6e400001-b5a3-f393-e0a9-e50e24dcca9e');
log('Getting Serial Port Write Characteristic...');
writeCharacteristic = await service.getCharacteristic('6e400002-b5a3-f393-e0a9-e50e24dcca9e');
log('Getting Serial Port Read Characteristic...');
readCharacteristic = await service.getCharacteristic('6e400003-b5a3-f393-e0a9-e50e24dcca9e');
log('Enabling notifications...');
await readCharacteristic.startNotifications();
readCharacteristic.addEventListener('characteristicvaluechanged', handleData);
device.ongattserverdisconnected = handleDisconnect; // Assigning the disconnect handler
log('Connected to ' + device.name);
document.getElementById('connectButton').disabled = true;
document.getElementById('disconnectButton').disabled = false;
} catch (error) {
log('Error: ' + error);
}
}
function handleDisconnect() {
log('Connection lost. Device disconnected.');
document.getElementById('connectButton').disabled = false;
document.getElementById('disconnectButton').disabled = true;
alert('Connection lost. Device disconnected.');
}
function disconnectFromDevice() {
if (device && device.gatt.connected) {
device.gatt.disconnect();
}
}
function handleData(event) {
const value = event.target.value;
const decoder = new TextDecoder('utf-8');
const data = decoder.decode(value);
log('Received: ' + data);
}
async function sendMessage() {
try {
const messageInput = document.getElementById('messageInput');
const message = messageInput.value;
const encoder = new TextEncoder('utf-8');
const data = encoder.encode(message);
await writeCharacteristic.writeValue(data);
log('Sent: ' + message);
messageInput.value = '';
} catch (error) {
log('Error: ' + error);
}
}
</script>
</body>
</html>
JavaScript
복사
